Description

Lever Block - HLB1600

1.6 T x 1.5 Metre

Overview

HAFCO 1.6T Lever Blocks are heavy duty and ideal for rigging, construction, and mining applications. They feature a Grade 80 alloy load chain and a robust, space-saving steel body.
The ID plates are made from stainless steel, and the unit contains no aluminium components. Each unit is AS 1418.2 compliant and supplied with a test certificate for quality assurance.

Features

Rated capacity: 1.6T
Ergonomically compact design
Built for durability in harsh and rugged environments
Quick and easy chain adjustment for fast load positioning
Suitable for use in underground mining and heavy-duty applications
Ball bearing-mounted to bottom hook enable smooth rotation under load
Tested at a NATA-accredited facility in accordance with AS 1418.2
Fully enclosed design with sealed gear and brake systems for superior protection and durability
The short arm lever and precision gear ratio allow minimal effort to lift heavy loads with maximum
HAFCO ID plates and rivets are made from stainless steel a non-conductive material for added safety and durability
Each HAFCO Lever Block is load-tested to its rated capacity and supplied with a HAFCO test certificate, traceable to its stamped identification side plate
