Wood Lathe - DURDEN TT400
Ø410mm Swing x 1000mm Between Centres
W294
1 of 1
Discontinued
Order Code: W294
415V / (NO PLUG)
1 Year Warranty
1 Year Warranty
Made in Australia
Description
Wood Lathe - DURDEN TT400
Ø410mm Swing x 1000mm Between Centres
Features
- Durden have been manufacturing wood working Machinery in Australia for many years
- Full cast iron beds, headstock and tailstock for increased rigidity
- Automatic tailstock centre ejection
- 24 hole indexing system
- Poly vee belt drive system
- Heavy duty steel cabinet stand with bolt down provision
- Bed interlocking system to allow you to extend the bed in 500mm sections
- Fitted with additional safety electrics
- Raised red (DOL) emergency stop switch
- Micro cut out switch fitted to belt cover
- Keyed lockable isolation switch
Includes
- 200mm right hand faceplate
- Faceplate spanner
- Spindle spanner
- 25mm spur centre
- 16mm cup centre, revolving type
- Boring cup centre
- Centre drift bar
- Right hand thread protector
- Rear spindle guard
- 150mm tool rest
- 300mm straight tool rest
- Curved tool rest
- Straight tool rest bracket and spanner, locking clamp
- Track and slider mechanism for dust extraction 5" diameter
- 50mm cup chuck
- Instruction manual and spare parts list
Compare Product Range
Specifications
| ORDER CODE | W294 |
|---|---|
| MODEL | TT-400 |
| (mm)Swing Over Bed | 410 |
| (mm)Between Centres | 1000 |
| Spindle Nose Thread | 30 x 3.5mm |
| (rpm)Spindle Speeds | ~ |
| (kW / hp)Motor Power | 0.75 / 1 |
| (V / amp)Voltage / Amperage | 415 |
| (mm)Floor Space (W x D x H) | 1169 x 630 x 1400 |
| (kg)Nett Weight | 250 |
On Sale
On Sale
On Sale
Discontinued
Discontinued
Discontinued
Discontinued
On Sale
On Sale
On Sale
Discontinued
Discontinued
On Sale
On Sale
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
Discontinued
- Compare:
- Wishlist:
- ORDER CODE
- MODEL
- (mm)Swing Over Bed
- (mm)Between Centres
- Spindle Nose Thread
- (MT)Spindle Nose Taper
- (rpm)Spindle Speeds
- (MT)Tailstock Taper
- (kW / hp)Motor Power
- (V / amp)Voltage / Amperage
- (mm)Floor Space (W x D x H)
- (mm)Floor Space With Option Stand (W x D x H)
- (kg)Nett Weight
- (ex-gst)Pricing
- (inc-gst)
- On Sale
-
Compare
-
Wishlist
- W385
- WL-14V
- 356
- 470
- M30 x 3.5 Pitch
- 2
- 2 Steps, Variable Spped
450~1800 & 900 ~ 3850 - 2
- 0.55 / 0.75
- 240 / 10
- 1000 x 350 x 460
- 1050 x 620 x 1220
- 46
- $544.55
- $599.00
- ADD TO CART
- On Sale
-
Compare
-
Wishlist
- W382
- WL-18
- 310
- 900
- 1" x 10TPI
- 2
- Variable 500 - 2000
- 2
- 0.75 / 1
- 240 / 10
- 1610 x 650 x 1120
- ~
- 85
- $635.45
- $699.00
- ADD TO CART
- On Sale
-
Compare
-
Wishlist
- W384
- WL-20
- 370
- 1100
- 1" x 10TPI
- 2
- Variable 500 - 2000
- 2
- 0.75 / 1
- 240 / 10
- 1650 x 680 x 1165
- ~
- 97
- $726.36
- $799.00
- ADD TO CART
- On Sale - Package Deal
-
Compare
-
Wishlist
- K021
- WL-20 Package
- 370
- 1100
- 1" x 10TPI
- 2
- Variable 500 - 2000
- 2
- 0.75 / 1
- 240 / 10
- 1650 x 680 x 1165
- ~
- 108
- $1,044.55
- $1,149.00
- ADD TO CART
- On Sale - Package Deal
-
Compare
-
Wishlist
- K0211
- WL-18 Package
- 310
- 900
- 1" x 10TPI
- 2
- Variable 500 - 2000
- 2
- 0.75 / 1
- 240 / 10
- 1610 x 650 x 1120
- ~
- 85
- $900.00
- $990.00
- ADD TO CART
- On Sale
-
Compare
-
Wishlist
- W387
- WL-46A
- 462
- 1194
- 30 x 3.5mm
- 2
- Variable 100 - 3200
- 2
- 1.5 / 2
- 240 / 10
- 2130 x 630 x 1220
- ~
- 228
- $2,180.00
- $2,398.00
- ADD TO CART
- On Sale - Back In Stock Soon
-
Compare
-
Wishlist
- W686
- WL-52
- 520
- 910
- M30 x 3.5p
- 2
- Variable 50 - 3890
- 2
- 1.5 / 2
- 240 / 10
- 1870 x 650 x 1250
- ~
- 392
- $4,680.00
- $5,148.00
- ADD TO CART
