250mm Easson Digital Readout Scale
VS10 Standard Scale
5µm Resolution
D721
1 of 4
DSub9 Male Plug
2 of 4
Dsub9 Wiring Diagram
3 of 4
DIY Installation
4 of 4
Order Code: D721
ex-gst
inc-gst
$
200.00
$
220.00
1 Year Warranty
Description
250mm Easson Digital Readout Scale
VS10 Standard Scale
5µm Resolution
Overview
Easson VS series Glass Grating Linear Transducer: EASSON - Always committed to Quality, Technology & Innovation
Features
- DOUBLE SEAL DESIGNED SCALES:
- The plastic seals of the transducer use an innovative material to offer superior oil resistance, high elastic recovery properties and durability, carefully designed lip geometry offer low slide resistance.
- 100% LASER CALIBRATION:
- All glass grating transducers are individually inspected and calibrated by our in-house laser calibrator to ensure accuracy complies 100% with the specifications.
- ADVANCED OPTICAL MEASURING SYSTEM:
- The slide carrier of the VS series scales, use a five bearing design for optical grating linear transducer which has been proven as the most reliable system design in today's market.
- The glass grating slide-ways are lapped, and JIS standard P5 grade bearings are used to achieve smooth and accurate movement and long working life.
- D.I.Y. INSTALLATION:
- An easy-to-follow D.I.Y. Installation Manual is supplied with each system, complete with illustrations and mounting brackets.
Compare Product Range
Specifications
| ORDER CODE | D721 |
|---|---|
| Type | VS10 Standard Scale |
| (mm)Travel - Maximum | 250 |
| (mm)Overall Length (L) | 396 |
| (µm)Scale Resolution | 5 |
| (µm)Accuracy | ±3 - ±5 |
| (Metre)Cable Length | 3 |
| (mm)Width x Height (W x H) | 27.5 x 3.5 |
| (Yes / No)Backing Support Plate | Yes |
